Chapter2–InstallingandCablingtheMultiVOIP

10 MultiVOIP®Voice/FaxoverIPGateways

MVP410/810modelscontentlist

● MVP410orMVP810

● DB9toDB25cable

● Mountingbracketsandscrews

● Powercord

● PrintedCablingGuide

MountingMVP410andMVP810inRacks

YoucanmounttheMultiVOIPsinanindustry‐standardEIA19‐inch rackenclosure.

SafetyRecommendationsforRackInstallations

Ensureproperinstallationoftheunitinaclosedormulti‐unitenclosurebyfollowingtherecommended

installationasdefinedbytheenclosuremanufacturer.Donotplacetheunitdirectlyontopofotherequipment

orplaceotherequipmentdirectlyontopoftheunit.Ifinstallingtheunitina

closedormulti‐unitenclosure,

ensureadequateairflowwithintheracksothatthemaximumrecommendedambienttemperatureisnot

exceeded.Ensurethattheunitisproperlyconnectedtoearthgroundbyverifyingthatitisreliablygrounded

whenmountedwithinarack.Ifapowerstripisused,ensure

thatthepowerstripprovidesadequategrounding

oftheattachedapparatus.

Whenmountingtheequipmentintherack,makesuremechanicalloadingiseventoavoidahazardous

condition.Therackusedshouldsafelysupportthecombinedweightofalltheequipmentit supports.

Ensurethatthemainssupplycircuitiscapableofhandlingtheloadoftheequipment.Seethepowerlabelonthe

equipmentforloadrequirements(fullspecificationsforMultiVOIPmodelsarepresentedinchapter1ofthismanual).

Thisequipmentshouldonlybeinstalledbyproperlyqualifiedservicepersonnel.Onlyconnect

likecircuits‐connectSELV

(SecondaryExtraLowVoltage)circuitstoSELVcircuitsandTN(TelecommunicationsNetwork)circuitstoTNcircuits.

Installinginto19InchRack

AttachingtheMultiVOIPtoarack‐railofanEIA19‐inchrackenclosurerequirestwopeople.

YoumustattachthebracketstotheMultiVOIPchassiswiththescrewsprovided,asshownthefirstfigurethat

follows,andthensecureunittorackrailsbythebrackets,asshowninthe

secondfigurethatfollows.Because

equipmentracksvary,screwsforrack‐railmountingarenotprovided.Followtheinstructionsoftherack

manufacturerandusescrewsthatfit.

1. Positiontherightrack‐mountingbra cketontheMultiVOIPusingthetwoverticalmountingscrewholes.

2. SecurethebrackettotheMultiVOIPusingthetwoscrewsprovided.

3. Positiontheleftrack‐mountingbracketontheMultiVOIPusingthetwoverticalmountingscrewholes.

4. SecurethebrackettotheMultiVOIPusingthetwoscrewsprovided.

5. Removefeet(4)fromtheMultiVOIPunit.

6. MounttheMultiVOIPintherackenclosure.Usetherackmanufacture’smountingproceduretodoso.


