 Chapter6—UsingtheSoftware

MultiVOIP®Voice/FaxoverIPGateways 123

MultiVOIPProgramMenuItems

AfteryouhaveinstalledtheMultiVOIPprogramonthePC,youcanlaunchitfromtheProgramsgroupofthe

WindowsStartmenu(Start|Programs|MultiVOIPx.xx|…).Thissectiondescribesthesoftwarefunctions

availableonthismenu.



Severalbasicsoftwarefunctionsareaccessiblefrom

theMultiVOIPsoftwaremenu,asshownbelow.

MultiVOIPProgramMenu

MenuSelection Description

Configuration SelectthistoentertheConfigurationprogramwherevaluesforIP,telephony,andother

parametersareset.

ConfigurationPortSetup SelectthistoaccesstheCOMPortSetupwindowoftheMultiVOIPConfiguration

program.

DateandTimeSetup Selectthisforaccesstosetcalendar/clockusedfordatalogging.

DownloadFactoryDefaults Selectthistoreturntheconfigurationparameterstotheoriginalfactoryvalues.

DownloadFirmware Selectthistodownloadnewversionsoffirmwareasenhancementsbecomeavailable.

DownloadIFMFirmware

SelectthistodownloadnewversionsofIFMfirmwareasenhancementsbecome

available.TheInterfaceModule(IFM)isthetelephonyinterfaceforanalogMultiVOIP

units..ThereisoneIFMforeachchanneloftheMultiVOIPunit.Foreachchannel,theIFM

handlestheanalogsignalstoandfromthe

attachedtelephone,PBXorCOline.

DownloadUserDefaults

Tobeusedafterafullsetofparametervalues,valuesspecifiedbytheuser,havebeen

saved(usingSaveSetup).Thiscommandloadsthesaveduserdefaultsintothe

MultiVOIP.

SetPassword

SelectthistocreateapasswordforaccesstotheMultiVOIPsoftwareprograms(Program

groupcommands,Windowsinterface,webbrowserinterface,&FTPserver).Onlythe

FTPServerfunctionrequiresapasswordforaccess.TheFTPServerfunctionalsorequires

thatausernamebesetalongwiththe

password.

Uninstall

SelectthistouninstalltheMultiVOIPsoftware(most,butnotallcomponentsare

removedfromcomputerwhenthiscommandisused).

UpgradeSoftware

Loadsfirmware(includingH.323stack)andsettingsfromthecontrollerPCtothe

MultiVOIPunit.UsercanchoosewhethertoloadFactoryDefaultSettingsorCurrent

Configurationsettings.
