 Chapter4–ConfiguringYourMultiVOIP

MultiVOIP®Voice/FaxoverIPGateways 45

ConfiguringFXSLoopStartParameters

ThefigureandtablethatfollowdescribetheparametersapplicabletoFXSLoopStart.



FXSLoopStartInterface:ParameterDefinitions

FieldName Values Description

DialingOptionsfields

FXS(LoopStart) Y/N EnablesFXSLoopStartinterfacetype.

InterDigitTimer 1‐10seconds Thisisthelengthoftimethatthe MultiVOIPwaitsbetweendigits.Whenthe

timeexpires,theMultiVOIPlooksintheoutboundphonebookforthenumber

enteredandplacethecallaccordingly.

Default=2.

MessageWaitingIndication ‐‐ Notapplicableto–SSseriesMultiVOIPs.

InterDigitRegeneration

Time

inmilliseconds



ThelengthoftimebetweentheoutputtingofDTMFdigits.

Default=100ms.

FXSOptionsfields

FXSRingCount,FXS 1‐10 MaximumnumberofringsthattheMultiVOIPissuesbeforegivingupthe

attemptedcall.

CurrentLoss Y/N Whenenabled,theMultiVOIPinterruptsloopcurrentintheFXScircuitto

initiateadisconnection.ThistellsthedeviceconnectedtotheFXSporttohang

up.TheMulti‐VOIPcannotdropthecall;theFXSdevicemustgoonhook.

GenerateCurrentReversal Y/N Whenselected,thisoptionimplementsAnswerSupervisionandDisconnect

SupervisiontotheFXOinterfaceusingcurrentreversaltoindicateevents.

ApplicableonlywhenFXSandFXOinterfacesareconnectedbacktoback.

Tableiscontinuedonnextpage…
